Features
- Minimal energy use with highest efficiency hydraulic design.
- Fully corrosion-resistant exterior, suitable for corrosive and saline environments.
- Fully enclosed, leak-free construction
- IE5 efficiency motor, realizing maximum energy-saving potential.
- Quiet operation, suitable for cleanroom applications.
- Small and light, facilitating easy installation and operation.
- Smallest installation footprint, maximizing space utilization.
Specification
- Pump Capacity: Up to 51 m3/h (850 lpm or 225 GPM)
- Pump Head: Up to 37 m (121 ft)
- Power Range: 1.1 kW - 4.0 kW (1½ - 5½ hp)
- Casing Material: GFRPP, CFRETFE
- Type: Horizontal, Single Stage, Centrifugal
- Construction: Canned Motor, Sealless
Family of pumps
| Model | AVF-C221 | AVF-C441 | AVF-C553 AVF-C543 | AVF-C653 | AVF-C555 AVF-C545 | AVF-C655 | AVF-C86G | AVF-C86J |
Suction x Discharge (mm)
|
25 x 25
|
40 x 40
|
50 x 50 50 x 40 | 65 x 50 |
50 x 50 50 x 40 | 65 x 50 | 80 x 65 | 80 x 65 |
Capacity Range (l/min)
|
10 - 180
|
20 - 300
|
40 - 500
|
60 - 600
|
60 - 550
|
80 - 850
|
80 - 1300
|
80 - 1400
|
Head Range (m)
|
6 - 23
|
5 - 20
|
8 - 31
|
4 - 22
|
8 - 37
|
7 - 30
|
10 - 33
|
10 - 37
|
Motor Output (kW)
|
1.1
|
1.1
|
2.2
|
2.2
|
4.0
|
4.0
|
5.5
|
7.5
|
Application
Printed Circuit Board (PCB) Industry
